Single-Phase 2P Top-in-Bottom-Out Latching Relay

The Single-Phase 2P Top-in-Bottom-Out Latching Relay(long type) is designed for applications that require larger internal space and multifunctional wiring. Compared with traditional short relays, the long design not only provides excellent current carrying capacity, but also effectively improves heat dissipation performance. This relay is suitable for complex circuit control, greatly improving the flexibility and reliability of the equipment, and is very suitable for use in industrial automation, smart homes, and various electrical distribution facilities.

（COIL SPECIFICATION）20℃

Product Features:

1. Design Advantages:

Extended internal space: The long design allows more components and more complex electrical structures, reduces the size limit of the circuit board, and facilitates the implementation of complex control functions.

2. Optimized thermal management: The larger volume helps to improve the heat dissipation effect and effectively prevents performance degradation or failure due to overheating.

3. Wiring method:

Top-in and bottom-out: The top-in and bottom-out wiring design not only reduces the tediousness of wiring, but also improves the efficiency of cable wiring, making the wiring of the entire electrical cabinet neater and more orderly.

4. Importance: Low sampling resistance can effectively reduce the heat generated by the equipment during operation, thereby enhancing the reliability of the relay and related circuits.

Application areas

Suitable for use in electrical control panels, industrial equipment, smart homes and complex automation systems. Its multifunctional contacts can control a variety of electrical equipment to meet different electrical needs.

1. Safety first: Make sure to disconnect the power supply before installation to ensure user safety.

2. Fixed installation: Install the relay firmly on the standard rail.

3. Wiring guide: Make cable connections according to the selected welding style (wire welding or welding pin plug board).

4. Test: After turning on the power, test the relay function to ensure normal operation.

Instructions for use

1. The factory state of the magnetic latching relay is the contact closed state (reset state), but due to the impact of factors such as transportation or relay installation, the state may change, so it is necessary to take measures to reset it before use.

2. In order to ensure the reliable operation of the magnetic latching relay, the excitation voltage applied to the coil must reach the rated value, and the pulse width must reach more than 3 times the action time.

3. Make sure to use it within the rated current and voltage range to avoid exceeding its load capacity. Check the contact points and wiring conditions regularly to ensure good connection and stable working conditions.

4. During use, do not drop, throw, throw, or drop the product from a high altitude, which will affect the performance of the product. If any abnormality is found, please immediately turn off the power for inspection to ensure the safety of the equipment.

Packing specifications: 360 per box

Warranty period: 1 year (excluding man-made damage)

Price: Please contact the sales department for the latest quotation and ordering information.
