Three-phase 7P Rail Type Latching Relay

This Three-phase 7P Rail Type Latching Relay adopts an advanced integrated design, fully considering the stability and safety under high load conditions. Whether in complex power systems or harsh industrial environments, relays can work safely and stably. Its 7P wiring design makes the installation process simple and efficient, and safe wiring can also reduce the risk of failure. High-quality latching relays can meet a variety of application needs. If you need them, please get our latching relay services online in time. In addition to the product list below, you can customize your own unique latching relay based on your specific needs.

（COIL SPECIFICATION）20℃

Features

100A high rated current: supports the needs of high-power three-phase power systems and is suitable for a variety of industrial applications.

Wide range of driving voltage: adaptable to power input from 6VDC to 48VDC, flexible and convenient.

Magnetic holding technology: It consumes almost no power in the holding state, significantly reducing operating costs.

Fast response mechanism: It has extremely fast switching speed to ensure the synchronization and accuracy of current monitoring.

Can be matched with the corresponding housing: with 7P terminal block: convenient for wiring, suitable for installation in various industrial environments.

Application areas

Three-phase 7P guide rail magnetic latching relay is widely used in the following fields:

Power monitoring system: Used in conjunction with three-phase wall meters and power meters to monitor current and voltage status in real time.

Industrial automation: Provide current control and overload protection for various types of industrial equipment to ensure equipment safety and efficiency.

Intelligent building management: Improve the building’s power management system and optimize energy efficiency.

Renewable energy: In solar and wind power generation systems, monitor current output to improve system stability.

1. Preparation: Make sure the power is turned off and prepare necessary tools (such as screwdrivers, wrenches, etc.).

2. Guide rail installation:

- Fix the relay on the DIN-standard guide rail and hear a "click" to confirm the fixation.

3. Wiring:

- Connect the power supply and load according to the wiring diagram, making sure all connection ports are secure and secure.

4. Functional test: Before turning on the power, check all wiring again to ensure there is no short circuit, and start the system for functional testing.

Instructions for use

1. The factory state of the magnetic latching relay is the contact closed state (reset state), but the state may change due to factors such as impact during transportation or installation of the relay. Therefore, it is necessary to take measures to reset it before use.

2. In order to ensure reliable operation of the magnetic latching relay, the excitation voltage applied to the coil must reach the rated value, and the pulse width must reach more than 3 times the action time.

3. Make sure to use it within the rated current and voltage range to avoid exceeding its load capacity. Regularly check the contact points and wiring to ensure good connections and stable working conditions.

4. During use, do not drop, throw, throw or drop the product from high altitude. This will affect the performance of the product. If any abnormality is found, please cut off the power immediately for inspection to ensure the safety of the equipment.
